Product Description
The faceted bell copper range hood combines a chamfered rectangular apron, concave bell canopy, and compact chimney in a balanced architectural composition available for wall-mount or kitchen-island installation. Formed from 16-gauge copper, the hood is organized into three distinct zones: a grounded lower base, narrowing bell body, and squared upper block. Two 45-degree front chamfers soften the apron without turning it into a true octagonal structure. The unadorned silhouette suits Pueblo Revival, California Mission, Territorial, restrained Spanish Revival, traditional, and transitional kitchens. Widths range from 28 to 78 inches, heights from 24 to 72 inches, and the standard depth is 24 inches. Smooth or hammered textures, six artisan copper finishes, custom dimensions, and insert preparation are available. Find planning tips and design inspiration in our Mission-style bell copper range hood guide. Request a custom quote for this Pueblo Revival copper range hood today.
Product Summary
- Product: faceted bell copper range hood
- Mount: wall or island installation
- Shape: concave bell with faceted apron
- Material: handcrafted 16-gauge copper
- Sizes: 28–78 wide; 24–72 inches high
- Surface: two textures and six finishes
- Ventilation: 200–1500 CFM options
- Lead time: approximately eight weeks
- Shipping: free mainland U.S. freight
- Origin: Mexico; 12-month shell warranty
Faceted Bell Design
This design relies on architectural geometry rather than straps, rivets, medallions, or embossed ornament. The broad rectangular apron has two front corners cut back at approximately 45 degrees, creating angled planes and controlled shadows that reduce its apparent visual weight while preserving the depth needed for ventilation equipment and cooking-area coverage. The apron is not a true octagon because its rear and side geometry remains rectangular, producing only a shallow octagonal reading from the front.
Three-Zone Hood Architecture
The composition follows a clear base, bell, and chimney hierarchy. A low horizontal apron anchors the hood above the cooking surface, the tall central canopy introduces the primary curved movement, and the rectangular chimney completes the vertical axis. A defined seam between the apron and canopy creates a strong horizontal line that may align with adjacent cabinetry, open shelving, backsplash borders, or other architectural elements.
Faceted Lower Apron
The lower apron forms a broad rectangular housing with two chamfered front corners. Narrow angled planes connect the front panel with the side walls, making the base appear less box-like when viewed from the front or at an angle. The apron height, front-panel width, chamfer size, and side depth may be adjusted during customization, but these features should remain proportional to the canopy sweep, chimney width, range size, installation type, and selected ventilation equipment.
Concave Bell Canopy
Above the apron, the canopy walls sweep inward through a restrained concave curve. From the front, the body narrows gradually toward the chimney; from the side, the face leans back as it rises. This compound taper establishes the hood's bell-shaped identity while creating a secondary sloping profile. The curve remains smooth and architectural rather than deeply flared or trumpet-like.
Rectangular Chimney Block
The compact chimney uses straight vertical walls and a flat upper termination. Its squared geometry provides a quiet finish after the movement of the curved canopy, creates a practical route for coordinated ductwork, and connects the handcrafted copper body with cabinets, beams, wall panels, vigas, and other rectilinear kitchen elements.
Customization Options
Each hood is made to order and may be adapted to the proportions of the cooking wall or kitchen island. Buyers may adjust the overall width, total height, standard depth, apron height, chamfer width, bell sweep, chimney dimensions, upper opening, and internal preparation. Wall-mount and island versions are planned separately because support, finished surfaces, ceiling conditions, duct routing, and service clearances differ.
Copper Texture and Finish
Choose a smooth or hammered copper surface. Finish options include coffee, antique, natural, honey, green oxidized, and hand-polished copper. Smooth copper emphasizes the clean geometry of the chamfered apron and concave canopy, while hammered copper adds small hand-worked impressions that scatter light and strengthen the hood's rustic artisan character.
Custom Dimensions
Standard widths include 28, 30, 36, 42, 48, 54, 60, 66, 72, and 78 inches. Total height may range from 24 to 72 inches, and the standard depth is 24 inches. Project-specific proportions are reviewed before fabrication so the faceted apron, concave body, and rectangular chimney remain balanced within the available wall or island footprint, ceiling height, cabinet spacing, backsplash layout, and duct route.
Ventilation Planning
This range hood supports buyer-supplied inserts up to 1260 CFM and external blower systems up to 1500 CFM. Rustica House can supply the optional 200 CFM insert only. Any other insert, liner, blower, controls, lighting, filters, or duct components must be purchased separately by the buyer.
Ventilation equipment varies widely in CFM capacity, controls, finishes, lighting, blower type, ducting, service access, and price. Allowing buyer-supplied systems provides flexibility for project-specific performance and appliance requirements. Before production, provide the equipment manufacturer, model, overall dimensions, cutout dimensions, duct size, outlet direction, control location, lighting layout, filter access, electrical requirements, and installation instructions so the copper shell can be prepared correctly. Review our range hood insert guide before selecting equipment.
Wall-Mount Installation
For a wall-mounted hood, confirm the range width, mounting height, wall blocking, backsplash thickness, cabinet clearances, duct route, upper chimney opening, attachment points, and access for future insert service.
Kitchen-Island Installation
For an island hood, confirm the finished appearance of all visible sides, ceiling structure, suspension or attachment method, duct alignment, electrical routing, island dimensions, sightlines, and installation access before fabrication.
Buyer Planning Table
| Planning | What to Confirm | Why It Matters |
|---|---|---|
| Installation type | Wall mount or kitchen island | Determines support and finished surfaces |
| Hood width | Range and cabinet or island width | Sets coverage and visual scale |
| Total height | Wall and ceiling space | Balances the three architectural zones |
| Apron and chamfers | Apron height, front width, and corner angle | Defines the faceted lower profile |
| Bell sweep | Curve, taper, and upper transition | Shapes the main silhouette |
| Chimney block | Width, height, and upper opening | Coordinates the duct route and ceiling connection |
| Ventilation | Insert, blower, duct, controls, and service access | Guides internal preparation |
| Delivery access | Doors, stairs, hallways, and installation path | Supports safe crate movement and placement |
Product Specifications
- Type: custom faceted bell copper range hood
- Installation: wall mount or kitchen island
- Primary form: concave bell canopy
- Secondary form: sloping body
- Apron: faceted rectangular base
- Corners: two 45-degree front chamfers
- Chimney: compact rectangular block
- Material: 16-gauge copper
- Textures: smooth or hammered
- Finishes: six artisan copper options
- Width: 28 to 78 inches
- Height: 24 to 72 inches
- Depth: 24 inches standard
- Custom dimensions: available by review
- Applied artwork: none
- Ventilation: insert-ready copper shell
- Rustica House insert: optional 200 CFM
- Buyer insert: supported up to 1260 CFM
- External blower: supported up to 1500 CFM
- Shell warranty: 12 months
- Insert parts: 12-month replacement coverage
- Lead time: approximately eight weeks
- Delivery: free mainland U.S. freight
- Care: mild soap, water, and a soft cloth
- Production: made to order
- Origin: Santa Clara del Cobre, Mexico
- SKU: NQ10U4G38
Hand-Formed Copper Construction
The shell is produced through copper cutting, forming, joining, fitting, and hand-finishing. Each chamfer must meet the front and side panels cleanly, while the concave canopy transitions from a broad lower footprint to a narrower chimney opening. Smooth surfaces reveal subtle forming marks and natural metal variation, while hammered surfaces introduce small impressions that scatter light and soften daily wear. Finish tones, seam placement, canopy curves, chimney alignment, and hammer patterns may vary slightly because each hood is handcrafted rather than machine stamped. These natural differences contribute to the hood's artisan value and are not manufacturing defects. Learn more about this metalworking tradition in the Juan Carlos Hernández copper artisan guide.
Distinctive Unadorned Profile
This model differs from decorative Mission and Spanish Colonial hoods because it has no vertical straps, riveted bands, floral friezes, medallions, arches, or embossed artwork. It also differs from a true octagonal trumpet hood, which uses eight complete panels around its apron and canopy. Here, the lower structure remains rectangular and introduces facets only at the two front corners, creating a quieter Pueblo Revival interpretation defined by proportion, curvature, copper finish, and architectural shadow lines.
Best Kitchen Styles
The hood is especially appropriate for Pueblo Revival interiors with creamy plaster, rounded openings, exposed vigas, Saltillo flooring, handmade tile, stone counters, and dark wood cabinetry. California Mission kitchens may pair it with ivory walls, walnut, terracotta, limestone, or patterned tile, while Territorial rooms benefit from its simple historic geometry. The plain body can also complement restrained Spanish Revival, traditional, and transitional kitchens where tile, carved wood, ironwork, or stone already provides the principal ornament. Discover additional design applications in our faceted bell copper range hood lifestyle image gallery.
Faceted Bell FAQ
A: The design combines a concave bell canopy, compact rectangular chimney, and broad rectangular apron with two 45-degree front chamfers. The angled apron corners create a faceted profile without turning the hood into a true octagonal design.
A: Yes. Buyers may order a wall-mount or kitchen-island version. The installation type must be confirmed before production because support, finished surfaces, ceiling conditions, duct routing, and service access differ.
A: No. The apron remains rectangular with two chamfered front corners that create a shallow octagonal appearance from the front without forming a complete eight-sided structure.
A: Buyers may adjust the width, height, depth, apron proportions, chamfer size, canopy curve, chimney dimensions, and upper opening before the hood enters production.
A: The hood is available with a smooth or hammered surface and coffee, antique, natural, honey, green oxidized, or hand-polished copper finishes.
A: Rustica House can supply the optional 200 CFM insert only. The shell may also be prepared for compatible buyer-supplied internal inserts up to 1260 CFM or external blower systems up to 1500 CFM when complete specifications are provided before production.
A: Production takes approximately eight weeks. Free insured freight shipping is included within the mainland United States, and the handcrafted copper shell includes a 12-month warranty subject to the published warranty terms.
Customize Your Hood
Plan this Pueblo Revival copper range hood around the range or cooktop width, wall or island location, available height, cabinetry, backsplash, ceiling structure, duct route, ventilation equipment, and installation clearances. Confirm the apron dimensions, chamfer width, concave canopy sweep, chimney block, copper texture, artisan finish, and final proportions before production. Request a custom quote from Rustica House today.
Related Resources
- bell-shaped copper range hoods
- sloping copper range hoods
- custom copper range hoods
- copper hood shape guide
- range hood insert guide
- copper hood size guide
Shipping and Returns
Review insured freight delivery, inspection procedures, custom-order terms, and buyer responsibilities before approving production. Visit the shipping and returns page for current conditions and exclusions.
Warranty
The handcrafted copper shell includes a 12-month warranty, and replacement components for the optional Rustica House insert are covered for 12 months according to the applicable terms. Review the Rustica House warranty page before ordering.
Disclaimer: Handmade dimensions, canopy curves, chamfer widths, apron proportions, chimney alignment, seams, textures, finish tones, tool marks, and hammer patterns may vary slightly. These differences are expected characteristics of handcrafted metalwork and are not manufacturing defects. Lifestyle images are provided for inspiration only and may show optional features. All product images © Rustica House; unauthorized use is prohibited.
